Simplex Cable

Geometrical Characteristics

Model

332

432

532

632

732

Cable Type

?3.0

?2.4

?2.0

?1. 8

?1.6

Cable Dimension(mm)

2.8±0.05

2.35±0.05

1.95±0.05

1.75±0.05

1.55±0.05

Cable Weight(kg/km)

6.5

5.0

32

3.1

3.0

TBF Diameter(μm)

900±50

600±50

Mechanical Characteristics

Tensile Strength (N)

Long Term

60

Short Term

100

Crush Resistance (N/100mm)

Long Term

100

Short Term

500

Bending Radius(CM)

Dynamic

20xD( D:TBF Diameter)

Static

10xD(D:TBF Diameter)

Fiber

Fiber Type(core/cladding dimension)

9/125, 50/125, 62.5/125

Transmission Characteristics

SMF

50/125

62.5/125

1310/1550 (nm)

850/1300 (nm)

850/1300 (nm)

Attenuation (db/km)

≤0.4/0.3

≤3.5/1.5

≤3.5/1.5

Minimum Bandwidth (MHz km)

≥400/400

≥160/500

Environmental Characteristics

Storage Operating Temperature

-20°C~+ 60°C
